DIY Self-Assembly Rope Tensioner for 2mm Wire Rope with grub Screw M5 for External Thread
€4.82* / Stk
Unit price: 4,82 €* / Stk
Available, delivery time: 2-4 business days
Produkt-Highlights
Stainless steel cable tensioner for 2 mm wire rope:
- With M5 external thread, right-hand thread
- Rope tensioner length: 45 mm
- Grub screw length: 50 mm
- External thread length: 30 mm
- Made from high-quality stainless steel V4A 1.4401 (AISI316)
Fast delivery Fast shipping directly from our Hamburg factory & workshop
99.75% Satisfied customers across 82.000+ reviews
Product number: 1014612T-R Manufacturer Information
Customers who bought this item also bought
Screw-On Clamp / Clamping Head M6 for 2-6mm Wire Rope / V4A - 1.4401
Regular price: €4.72
Stainless Steel Clamping Head M6 for 2.0 - 4.0 mm Wire Rope
Regular price: €2.19
DIY Self-Assembly Rope Tensioner for 2mm Wire Rope with M5 / Right-Hand Internal Thread
Regular price: From €3.28
Stainless Steel Wire Rope 7x19 / 2.0mm / By The Meter
Regular price: €0.54
Stainless Steel Wire Rope 1x19 / 2.0mm / By The Meter
Variants from €0.35
Regular price: €0.62
Mini Fork Terminal M5 Right
Regular price: €1.79
Ringbolzen / Augbolzen mit Kragen und Holzgewinde 6 x 40mm, Edelstahl A4 - AISI 316
Variants from €3.10
Regular price: €3.45
Fender Eyelet Round 4mm
Regular price: €0.42
Stainless Steel Wire Rope 7x7 / 0.5mm / 250m Spool
Variants from €0.27
Regular price: €110.18 Stainless Steel Wire Rope 7x7 / 2.0mm / By The Meter
Variants from €0.27
Regular price: €0.38 Stainless Steel Clamping Head M8 for- 2.0 - 4.0mm Wire Rope
Regular price: €2.19
Product information "DIY Self-Assembly Rope Tensioner for 2mm Wire Rope with grub Screw M5 for External Thread"
Stainless steel cable tensioner for 2mm wire rope
Installation:
The wire rope is fully inserted into the hole and fixed in place by tightening the three grub screws. This secures the rope in the tensioner. The cable can be shortened to the required length on site, eliminating the need for time-consuming crimping. The terminal has an M5 internal thread on the opposite side into which the fastening screw is screwed. Tightening the fastening screw simultaneously tensions the rope.
However, it should be noted that the terminals are not suitable for suspended or load-bearing loads.
| article | Wire rope Ø | Thread - G | Ø 1 | Ø 2 | X | L1 | L2 |
| DIY2R | 2 | M5 - RH | 2,2 | 8 | 2x M5 | 45 | 20 |
