DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with Grub Screw M6 for External Thread / Left
€5.05* / Stk
Unit price: 5,05 €* / Stk
Available, delivery time: 2-4 business days
| Quantity | Unit price per Stk |
|---|---|
| 1 To 49 Stk | €5.05* |
| 50 To 99 Stk | €4.54* |
| Ab 100 Stk | €4.04* |
Produkt-Highlights
- Stainless steel cable tensioner for 4mm wire rope
- with M6 external thread left-hand thread
- Terminal length: 60mm
- Made from high-quality stainless steel V4A 1.4401 (AISI316)
- For mounting between metal posts
- This variant requires 2x right-hand thread or 1x right-hand and 1x left-hand thread terminal per cable
Fast delivery Fast shipping directly from our Hamburg factory & workshop
99.75% Satisfied customers across 82.000+ reviews
Product number: 1014614T-L Manufacturer Information
Customers who bought this item also bought
Stainless Steel Wire Rope 7x7 / 4.0mm / By The Meter
Variants from €0.27
Regular price: €1.28
Wall Bracket M10 Internal Thread, 130mm Wall Distance
Regular price: €15.53
Stainless Steel Socket Screw M10x100 without Wrench Flat
Variants from €0.45
Regular price: €1.00
Carbiner 5x50mm / Stainless Steel A4 - 1.4401
Regular price: €0.95
Carbiner 4x40mm / Stainless Steel A4 - 1.4401
Regular price: €0.95
Rope Cross Clamp M10 open for 3.0 - 4.0 mm Wire Rope
Variants from €2.73
Regular price: From €2.92
DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with Fork End M6 / Right
Regular price: From €4.70
DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with M6 Eye End / Right
Regular price: From €4.70
Stainless Steel Wire Rope 7x19 / 4.0mm / By The Meter
Variants from €0.54
Regular price: €1.39 Product information "DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with Grub Screw M6 for External Thread / Left"
Installation:
The wire rope is fully inserted into the hole and secured by tightening the three grub screws. This secures the rope in the tensioner. The cable can be shortened to the required length on site, eliminating the need for time-consuming crimping. The terminal has an M6 internal thread on the opposite side into which the fastening screw is screwed. Tightening the fastening screw simultaneously tensions the rope.
However, it should be noted that the terminals are not suitable for suspended or load-bearing loads
The wire rope is fully inserted into the hole and secured by tightening the three grub screws. This secures the rope in the tensioner. The cable can be shortened to the required length on site, eliminating the need for time-consuming crimping. The terminal has an M6 internal thread on the opposite side into which the fastening screw is screwed. Tightening the fastening screw simultaneously tensions the rope.
However, it should be noted that the terminals are not suitable for suspended or load-bearing loads
.DIY self-assembly - Terminal
| article | Wire rope Ø | Thread - G | Ø 1 | Ø 2 | X | L1 | L2 |
| DIY4i | 4 | M6 - LH | 4,4 | 12 | 3x M6 | 60 | 16 |
External thread M6
| article | Wire Ø | Thread - G | L 1 | L 2 | L |
| bLR6 | - | M6 - RH / LH | 30 | 30 | 66 |
