DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with M6 Hanger Bolt / Right
€6.59* / Stk
Unit price: 6,59 €* / Stk
Available, delivery time: 2-4 business days
| Quantity | Unit price per Stk |
|---|---|
| 1 To 49 Stk | €6.59* |
| 50 To 99 Stk | €5.93* |
| Ab 100 Stk | €5.27* |
Produkt-Highlights
Stainless steel cable tensioner for 4mm wire rope
- For mounting between posts and walls in wood or with dowels in stone, concrete or granite
- With M6 socket screw right-hand thread
- Length: 60mm
- Made from high-quality stainless steel V4A 1.4401 (AISI316)
- This variant requires 1x right-hand and 1x left-hand thread terminal per cable
Fast delivery Fast shipping directly from our Hamburg factory & workshop
99.75% Satisfied customers across 82.000+ reviews
Product number: 1014614S-R Manufacturer Information
Customers who bought this item also bought
Stainless Steel Wire Rope 7x7 / 4.0mm / By The Meter
Variants from €0.27
Regular price: €1.28
Hanger Bolt Right-Hand Thread M6 Mini
Variants from €1.41
Regular price: €1.69
Stainless Steel Wire Rope 7x19 / 4.0mm / By The Meter
Variants from €0.54
Regular price: €1.39
Rope Cross Clamp Mini for 4.0 mm Wire Rope
Variants from €1.65
Regular price: €2.09
DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with M6 Eye End / Left
Regular price: From €4.70
Hanger Bolt Left-Hand Thread M6 Mini
Variants from €1.41
Regular price: €2.29
Stainless Steel V4A End Cap for Wire Ropes / 4mm
Variants from €0.39
Regular price: €0.45
PYTHON Stainless Steel Wire Rope 4.0mm / By The Meter
Variants from €1.57
Regular price: From €3.81
Hexagon Nut M6L- DIN 934/A4 Left-Hand Thread
Variants from €0.25
Regular price: €0.29 Stainless Steel Wire Rope 7x7 / 6.0mm / By The Meter
Variants from €0.27
Regular price: €2.23
Stainless Steel Clamp Stopper SW for 4mm Wire Rope / KS4-4
Variants from €3.64
Regular price: €3.76
Carbiner 10x100mm / Stainless Steel - A4 - 1.4401
Variants from €0.95
Regular price: €3.72 Product information "DIY Self-Assembly Rope Tensioner for 4mm Wire Rope with M6 Hanger Bolt / Right"
Installation:
The wire rope is fully inserted into the hole and secured by tightening the three grub screws. This secures the rope in the tensioner. The cable can be shortened to the required length on site, eliminating the need for time-consuming crimping. The terminal has an M6 internal thread on the opposite side into which the fastening screw is screwed. Tightening the fastening screw simultaneously tensions the cable.
However, it should be noted that the terminals are not suitable for suspended or load-bearing loads.
Self-assembly terminal
| Item No. | Wire rope Ø | Thread - G | Ø 1 | Ø 2 | X | L1 | L2 |
| DIY4i | 4 | M6 - RH | 4,4 | 12 | 3x M6 | 60 | 16 |
Hanger bolt M6
| article | Wire Ø | Thread - G | L 1 | L 2 | L |
| bST6 | - | M6 - RH-LH | 50 | 30 | 85 |
