GLEISTEIN Gemini X - 4mm / Breaking load 1400daN - white/red
€3.26*
Available, delivery time: -
| Quantity | Unit price per Meter |
|---|---|
| 1 To 9 Meter | €3.26* |
| Ab 10 Meter | €2.95* |
Product information "GLEISTEIN Gemini X - 4mm / Breaking load 1400daN - white/red"
Gleistein DynaOne HS Max – Dyneema DM20 Performance Line
Product Description
DynaOne HS Max is a heat-set 12-strand Dyneema DM20 performance line engineered for static high-load applications. It combines extremely low creep behaviour with minimal elongation and very high linear breaking load. Designed for structural onboard applications where constant length stability is critical.
Dyneema DM20 is developed specifically for permanent static loads. Heat setting optimises fibre alignment and reduces working elongation. This makes DynaOne HS Max ideal as a Dyneema control line for high-load backstay trim systems.
The pure 12-strand single braid construction allows easy splicing while maintaining dimensional stability. Without a cover, the focus remains entirely on maximum core strength at minimal diameter and weight.
Advantages at a glance
- 12-strand braid made from Dyneema DM20
- extremely low creep under sustained load
- heat-set for dimensional stability
- very high linear breaking load
- minimal elongation
- easy to splice
- available by the meter
- custom made options available
Technical Data
| Diameter | Linear breaking load |
|---|---|
| 3mm | 1100 daN |
| 4mm | 1750 daN |
| 5mm | 2730 daN |
| 6mm | 3500 daN |
| 8mm | 7000 daN |
| 10mm | 9300 daN |
Construction: 12-strand braid
Material: Dyneema DM20
Elongation at 10% break load: 0.3%
Execution: available by the meter / custom made
Custom Made
DynaOne HS Max is available by the meter. Optional D-Pro eye splice or D-Pro eye splice with low friction ring up to 10mm.
Please specify required length and preferred end configuration for your Dyneema backstay control system.
Typical Applications
- control line for adjustable backstay
- backstay trim systems
- static high-load trim connections
- structural lashings
- Dyneema wire replacement
- high-load fixing points
Our Recommendation for Your Boat
DynaOne HS Max is recommended as a Dyneema control line for adjustable backstay systems. Its extremely low creep behaviour makes it suitable for statically pre-tensioned backstay trim systems under sustained load.
- adjustable backstay control line
- Dyneema backstay trim
- static high-load control systems
- structural fixing connections
Meta-Title
Meta-Description
| Color: | Grey |
|---|---|
| Marke: | Gleistein |
| Durchmesser/mm: | 4 |
| Einsatzbereich: | High Performance, Performance, Regatta |
| Verwendung: | Achterstag, Backtagen, Fallen, Strecker, Stroppen |
| Material / Kern: | Dyneema DM20 |
| Material / Mantel: | kein |
| Schwimmfähig: | ja |
| Dehnung: | < 1 % |
| Spleißbar: | ja |
| Stripfähig: | nein |
