Seldén PBB50 Single Sheave Plain Bearing Block with Swivel and Shackle / 50mm Sheave

Seldén PBB single-disc with bottom bracketSeldén

PBB plain bearing blocks for high loads, single-disc with bottom bracket

• Washers made of acetal
• Axles made of high-strength stainless steel
• Housing made of composite material
• Swivels can be fixed in longitudinal or transverse position

Designation	Item number	Disk Ø mm	Working load kg	Breaking load kg	Max. line Ø mm	Shackle-Ø mm	Pin-Ø mm
PBB40	9404-001-02	40	350	700	8	-	-
PBB50	9405-001-02	50	650	1300	12	5	5
PBB60	9406-001-02	60	1000	2000	14	6	6
PBB70	9407-001-02	70	1500	3000	14	6	8
PBB80	9408-001-02	80	2000	4000	16	8	10
